①Matt surface, ultra high contrast;
②10000nits level brightness, lower power consumption and screen temperature, longer lifetime;
③High luminous surface and low PINs height, convenient for glue filling and mask installation.
Product Name |
Color |
IF(mA) TEST |
λd(nm) Typ |
Iv(mcd) Typ |
Vf(V) Typ |
View angle (deg.) |
RS-2727MWAS
|
20 | 622 | 1048 | 2.0 | 110 | |
| 15 | 528 | 1826 | 2.8 | 110 | ||
| 10 | 474 | 261 | 2.8 | 110 |
